Joint STARS teams with 'Boneyard' to improve combat ID

  • Published
  • By Patty Welsh
  • 66th Air Base Wing Public Affairs
HANSCOM AIR FORCE BASE, Mass. --  Members of an Electronic Systems Center team are using an aircraft identified for parts reclamation, or re-use, to reduce cost, save time and minimize risk.

In 2008, the Joint Surveillance Target Attack Radar System (Joint STARS) program office at the Electronic Systems Center (ESC) received congressional funding to integrate and conduct a demonstration of the Senior Year Electro-optical Reconnaissance System (SYERS-3) on a Joint STARS aircraft. The SYERS-3 sensor provides electro-optical and infrared images which will provide aircrews combat identification and reduce fratricide.

The SYERS - 3 Integrated Product Team identified several risk areas with integrating this third generation U2 camera onto Joint STARS and contracted with Northrop Grumman Corp. (NGC) to perform a SYERS-3 Feasibility Study. During that initial study, engineers determined the best location for the SYERS-3 sensor would be mounted below the jet in an area known as the keel beam of the E-8C Joint STARS aircraft.

"As gaining access to the keel beam area is very difficult, NGC originally planned to utilize modeling for the work, which would have been both expensive and time-consuming," said Capt. David Wright, SYERS-3 program manager.

After some discussions, NGC and the 751st Electronic Systems Group decided to try to obtain an actual keel beam.

Mark Lawrence, 633rd Electronic Systems Squadron program manager, contacted the 309th Aerospace Maintenance and Regeneration Group (AMARG) at Davis-Monthan Air Force Base, Ariz., to see if one was available.

Capt. Wright said, "I've had a lot of past success working with AMARG supporting C-5s and C-130s."

Nicknamed the 'Boneyard' because of its use as a repository for retired aircraft, the 309th AMARG provides aerospace depot maintenance, aircraft regeneration, storage and preservation, aircraft parts reclamation and disposal in support of the Department of Defense, allied warfighters and other government agencies including NASA.

Personnel from ESC and AMARG began working together on the SYERS project in November 2008. They were able to identify a 707 aircraft, identical to operational jets in the Joint STARS fleet, which was available for parts reclamation.

"The individuals from ESC had a pretty good idea of what they were looking for, but not every aircraft would be ready for that type of work. Many had the landing gears gone or were up on modules," said Eric Paulley, maintenance specialist, AMARG. "Not only do we want to make sure it's what the customer needs, but we need to make certain the work can be done safely."

The lower center fuselage keel beam area was cut out of the aircraft and shipped to the Northrop Grumman facility in Melbourne, Fla.

"This was not a trivial task," Captain Wright said. The keel beam is more than 20 feet long and weighs 2,700 pounds."

Northrop Grumman used the AMARG-provided keel beam for load and stress evaluation, to determine component installation location, and prototype structural re-enforcement designs.

"The Joint STARS team has worked with AMARG since initial production and they have always provided us outstanding support," Mr. Lawrence said. "They have been key in keeping the SYERS-3 demonstration on track. Using AMARG is an excellent risk reduction tool."

"Having the keel beam on-site helped us work through our air worthiness certification approval process," said Captain Wright. "It directly contributed to the accomplishment of the SYERS program. We would not have been able to get as far as we have, with the certainty we have, without it."

The partnership continues as the Joint STARS team asked AMARG to brief their organization's mission and recent successes at the 2010 707 User's Group this coming April in Orlando, Fla.

"I was extremely impressed with the professionalism and skill displayed by AMARG," said Patrick Dagle, the director of the 751st ELSG. "Their willingness to partner with the Joint STARS program lowered our cost, shortened our schedule and decreased our risk for installing this critical combat identification capability. I look forward to working with them in the future."
